Our digital timer is a great way to manage your access control. The timer can be installed on any access control devices such as keypads, pushbuttons, GSM or remotes. This can engage/disengage the devices at any chosen time or day. We can also put a timer on the gate open/close input to open or close the gates at specific times and days.
If ordered with a new kit, the Timer will be installed and wired to control your requested equipment.
Specs:
* You can use the timer to turn on/off any electrical device at the preset timer
* 16 on/off programs per day, 15 combinations per week.
* Programmable 24/7.
* Built-in battery to back up memory in case of power outage (save your program settings)
* Repeat program has 16 on/off settings, and manually set on/off
* Easy to read LCD display with LED indicator
* Allowable ambient temperature: -10°C to 55°C
* Type C output, normally open, normally closed, universal, 1/4 quick connect
* Contact rating: resistance 16A, inductance 8A, motor 1/2HP
Specification:
Input voltage: 12VDC/AC
Output: 16amp, SPST @ 250Vac, Volts out.
Use: Programmable 24/7
Daily: 16 on/off programs
Programming combination: 15 groups
Power supply: 12 VDC 50/60Hz
Load: 16A
Battery: 1.2V/40mAh
12/24 hour clock: yes
